Octagonal Pole |
Hot Dip Galvanized Octagonal Pole
We use carefully selected, premium raw materials to create our specially designed hot dip galvanized octagonal poles. Being a reputable manufacturer of octagonal poles, we take pride in making sure that our poles are stronger and more stable than typical round poles. They are a popular option for contemporary infrastructure projects because of this. The use of premium materials and exacting production procedures gives these poles their longevity and functionality.
Our octagonal poles are distinguished by their ability to withstand corrosion, ease of installation, and fashionable appearance. Made of steel and iron, they provide a sturdy framework. The main applications for these poles are wire installations and street lighting.
State governments, colleges, schools, sports complexes and facilities, commercial spaces, public areas, residential colonies, and any other location that needs bright illumination without interfering with user experience are among our clients.
Technical Data Sheet of 3 mtr to 13 mtr Octagonal Pole
We are a trusted manufacturer of octagonal poles with a focus on hot dip galvanized poles with heights ranging from 3 to 13 meters. Our poles are made to be strong, long-lasting, and resistant to corrosion. Each pole is galvanized to withstand even the most severe weather conditions and is made from premium steel using state-of-the-art technology. These octagonal poles are ideal for a range of outdoor lighting requirements because they not only offer outstanding structural performance but also give streets, highways, and industrial areas a little aesthetic appeal.
You don't need to search any farther for a trustworthy GI pole manufacturer! National and international quality standards are met in the design of our hot dip galvanized octagonal poles.
These poles offer long-lasting, low-maintenance performance for utility, lighting, and signage applications thanks to their tapered design and simple installation. Modern materials and meticulous construction are our top priorities in order to guarantee that every high mast pole we manufacture meets our clients' highest standards for performance and dependability.
Drawing of GI Octagonal Pole
The structural details of our octagonal poles, which come in lengths from 3 to 13 meters, are illustrated in this detailed technical diagram. Designed by Kasper Engineering, our poles guarantee safety, strength, and durability. Each GI octagonal pole (Galvanised Iron) is constructed from high-grade steel and hot-dip galvanized to resist corrosion in any climate. The octagonal design not only provides excellent wind resistance but also enhances the aesthetic appeal in urban and industrial settings. To ensure reliability and ease of installation, the design includes precise views of base plates, foundation bolts, door openings, and civil foundation structures. Built in accordance with IS and EN standards, our poles adhere to strict dimensional tolerances for top & bottom A/F, length, straightness, and thickness.
These GI octagonal poles are ideal for commercial areas, highways, and street lighting. Kasper Engineering offers a reliable solution for your long-term infrastructure needs.
Key Features of Octagonal Pole Manufacturing
Octagonal Pole Structure | Technical Specification |
|---|---|
Bracket
| Single Arm, Double Arm
|
Foundation Bolt Length
| 600Mm
|
Foundation Bolt Diameter
| 16Mm (Is2062 Gr. E250A)
|
Base Place Pcd | Pcd 200
|
Base Plate Size
| 200Mm X 200Mm X 12Mm (Is2062 Gr. E250A)
|
Type Of Locking Arrangement
| Close Fitting Bolt With Allen Key Bolt
|
Size Of Operning Door At Base
| 500Mm
|
Thickness Of Galvanization
| 65 Micron |
Metal Protection Treatment (Mast Section)
| Hot Tip Galvanized( As Per IS4759/IS2629)
|
Bottom Diameter
| 130Mm A/F
|
Top Diameter
| 70Mm A/F
|
Number Of Cross Sections (Sides) | 8 Sides
|
Thickness Of Sheet(In Mm)
| 3 Mm
|
Number Of Sections
| Single
|
Material Construction | Is2062 E250A
|
Height Of Octagonal Pole | 3 to 13 meter |
Brand | Kasper |
Product Images
Product Specifications
1
Technical
-
Automated Welding & Bending: Delivers consistent quality and strong structural performance.
-
CNC Cutting & Drilling: Delivers precise shapes and hole placements for easy installation.
-
Surface Treatment: Offers corrosion resistance with galvanizing, powder coating.
-
Quality Control: Equipped labs test strength, coating, and compliance.
2
Key Features
-
Custom Heights & Shapes: Tapered, conical, cylindrical, and polygonal designs.
- Modular Construction: Multi-section poles for easy transport and assembly.
-
Mounting Options: Brackets, base plates, access doors, and crossarms available.
-
Wind Load Compliance: Designed to meet EN, ASTM, and BS standards.
3
Product Advange
-
Durability: Corrosion-resistant materials and coatings ensure long service life.
-
Design Flexibility: Custom shapes, sizes, and finishes to suit any project.
-
Cost Efficiency: Modular design and long-lasting performance.
-
Sustainability: Eco-friendly materials and processes support green initiatives.
Types of Octagonal Pole
Successfully Delivered Project
Our Success Stories
Every Pole Tells a Story – Here’s Ours in One Frame
Motorised Flagpole लगाना हमारा पेशा,जोज़िला की चोटी पर तिरंगा लगाना हमारा भाग्य Kasper Group
30 MTR Flag Mast at Nasik, Maharashtra #kasperpoles #aima #30mtrflagmast #kaspermake #octagonalpole
Octagonal Pole | Lighting Poles | Manufacturer | Kasper Engineering
Flag Mast Pole | Indian Flag | Kasper Engineering | Lighting Poles Manufacturer | Uttar Pradesh
Our Clients
We believe each client is a long term partnership
Explore More
As a leading octagonal pole manufacturer, we ensure exceptional performance and durability through advanced materials and precision engineering—exceeding client expectations every time.
